Features:
1. Communication function: can monitor the battery information of voltage, current, capacity, temperature, etc.
2. Fast connect: adopt push-pull self-locking connector, which is efficient, safe and reliable.
3. Data communication management: adopt IC+TI charger management chip, precise data transmission and accurate
temperature control so as to try our best to eliminate the security risks.
4. The battery pack has good security, professional handle, nice low temperature performance and long cycle life.
5. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and
environmental protection.
6. Shock-resistant and waterproof: fill in the shock-resistant structure inside the cold rolling metal plate housing to
satisfy the requirements of good security and high reliability.
Basic specification:
Battery Capacity | 155Wh/42000mAh,3.7V |
194Wh/52400mAh,3.7V | |
Dimensions | 204*91*187mm |
Weight | About 1.89kg |
Input Reacharging | AC Adapter:DC15V/3A |
Solar Panel:MPPT,14V-22V/3A(Max) | |
Fully Charged Time | DC15V/3A:5-6hours |
DC15V/3A:6-7hours | |
DC Output | 2 x DC5521:9-12.6V/10A(14.5A Max) |
USB Output | 1 xUSB-A:5V/2.4A |
1 xUSB-A:QC3.0,5-12V/18W | |
1 xTYPE-C:PD 5-12V/18W | |
AC Output | The product provides Modified Sine Wave output. |
Rated Power:150W,Maximum Power:200W,Peak Power:300W. | |
The user manual is universal for all units in the range of AC100V-240V,50/60Hz. | |
The actual voltage and frequency will be different according to different countries and areas,please refer to the actual product before using. | |
LED Light | 2W Ultra bright LED Flashlight |
Power Indicator | LCD Display |
Operating Temperature | -10ºC~+40ºC |
Lifecycles | >500 times |
Package Contents | 1xPortable Power Supply |
1xAC Adapter | |
1xCar Charger | |
1xCigarette Lighter Adapter | |
1xUser Manual |
Main Applications :
AC+DC+ Car Charging +USB (PD) multiple power supply modes, no matter outdoor office equipment such as computer and
mobile phone, external shooting equipment such as UAV, camera, head, live lighting, or outdoor medical equipment such as
power tools and ventilators can be easily done, but also power supply partners such as RV fishing, more application scenarios
waiting for you to discover.
FAQ:
Q1: Are you Factory,How long to make Battery Pack?
A: We are the Professional Battery Factory,we Need 30day around if we dont have stock of that model.Coz need strictly
test and high temperature,high voltage life aging as well in every single Battery.That will takes a fixed date.
Q2: How to start the cooperate?
A: Lets start with the sample orders. In 5days will be ready the samples, then you test.We make the standard according
the data sheet which we give.Once you confirm the quality, we can talk for further.
Q3: What will be the packing?
A: We are using blister pallet packing in each battery pack. and then fold all packing in one ctn.
Q4: Can the connectors or PCB be customized?
A: Yes, we can choose the right connector according your requirement.Or help to match your device.
Q5: Is OEM/ODM battery pack available?
A: Yes, OEM/ODM battery packs are warmly welcome. Professional engineers provide technical support.
Q6: Do you have the documents required for battery shipments?
A: Yes, we have MSDS, UN38.3, etc. and other special files needed for shipments to some regions can also be secured.
