| Quantity: | |
|---|---|
LH-FP-HT-1C
FUNPACK
BMS
| Item | Content | Criterion |
| OVC | Over charge detection voltage | 4.250±0.050V |
| Detection delay time | 1.0±0.3S | |
| Over charge release voltage | 4.150±0.050V | |
| OVD | Over discharge detection voltage | 2.700±0.080V |
| Detection delay time | 1.0±0.3S | |
| Over discharge release voltage | 3.000±0.100V | |
| Rated operational current | ≤20A | |
| OCD | Primary over current detection current | 50±5A |
| Primary detection delay time | 800mS-1200mS | |
| Secondary over current detection curren | 100±10A | |
| Secondary detection delay time | 50mS-200mS | |
| Short protection | Detection condition | >200A, 200uS-300uS |
| Protection | yes Exist | |
| Protective release condition | Disconnect short circuit | |
| Charging management | Charging overvoltage protection voltage | 43.5±0.4V |
| Rated charging current | 3A | |
| Software overcharges | 4±0.2A | |
| Detection delay time | 300mS-600mS | |
| Temperature protection | Charging high temperature protection temperature | 50±4ºC |
| Charging protection recovery temperature | 47±4ºC | |
| Discharge high temperature protection temperature | 70±4ºC | |
| Discharge protection recovery temperature | 55±4ºC | |
| Low temperature protect temperature of charging | 0±4ºC | |
| Low temperature recovery temperature of charging | 5±4ºC | |
| Interior resistance | Main loop electrify resistance | ≤60mΩ |
| The static current | Since the power consumption | ≤60.0uA |
| NTC | YES Exist | 10K±1% B3435±1% |
OEM/ODM Service:
If you want to display your own brand logo in products, bags, labels or anywhere.
Our OEM and ODM services are ready to do it.
Delivery Time:
- Material Preparation Time: 7-15 days (or inventory)
- Production & Assembly Time 3-10 days
- Testing & Packaging Time: 2-10 days
- Total Delivery Time: 30-45days
- The faster delivery could be negotiable.
FAQ
Q1: Are your a factory or trading company?
A: We are a professional battery manufacturer with our own factory and brand. We provide all kinds of OEM/ODM services for clients, can produce by your samples or technical drawings. We can build the molds and fixtures.
Q2.Can I have a sample order?
A: Yes, we welcome sample orders to test and check quality.
Q3: Where can I get the price?
A: We will offer you the best quotation in 12 hours after we get the product specifications such as voltage capacity application etc.
Q4. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q5. How about your delivery time?
A: Generally, it will take 15-30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
