51.2V
FUNPACK
NLP LifePO4 battery is superior compared to lead acid batteries in following features
1.0 Degree charging cut off, designed with full protection.
2.1/2 Lower weight, high energy density.
3.1 Hour Fast Charging
4.Longer life, up to 4000 cycles.
5. 5 Years quality warranty.
6. 100% Power discharge without harm battery
Model | FP-AM15A |
Inverter Data | |
Rated Output Power | 5000W |
Peak Power | 10,000VA |
Rated Output Voltage | 230Vac, single-phase or three- phasewhen in parallel |
Load Capacity of Motors | 4HP |
Rated AC Frequency | 50/60Hz |
Waveform | pure sine wave |
Switch Time | 10ms（typical） |
Battery Data | |
Rated Battery Voltage | 48Vdc |
Voltage Range | 40～60Vdc |
Max. PV Charging Current | 100A |
Max. PV Charging Current | 60A |
Max. Hybrid Charging Current | 100A |
PV INPUT | |
Max. PV Array Power | 5,500W |
Max. Input Current | 22A |
Max. Open-circuit Voltage | 500Vdc |
MPPT Voltage Range | 120～450Vdc |
UTILITY / GENERATOR INPUT | |
Input Voltage Range 90～280Vac | |
Frequency Range | 50/60Hz |
Bypass Overload Current | 40A |
GENERAL | |
Num. of Paralle | 1~6 units |
Operating Temp. Range | Charge:-0~60℃, Discharge:-10~60℃ |
Cooling Method | intelligent fan |
Battery Data | |
Energy | 15.36Wh |
Capacity | 300Ah |
Max Charge Current | 100A |
Max Discharge Current | 100A |
Standard Charge Current | 100A |
Standard Discharge Current | 100A |
Designed Life-span | 5000 cycles |
Operation Humidity | 5 95% |
Nominal Operation Altitude | ＜3000M |
Communication | RS485/CAN |
IP Rating | IP20 |
Certification | / |
Net Weight | ~170KG |
Dimension(L*W*H) | 700*356*615mm |
Self-contained | |
Discharge port | 230V AC OUT*3 |
Charging port | 230V AC IN*1 |
FAQ
Q1: Are your a factory or trading company?
A: We are a professional battery manufacturer with our own factory and brand. We provide all kinds of OEM/ODM services for clients, can produce by your samples or technical drawings. We can build the molds and fixtures.
Q2.Can I have a sample order?
A: Yes, we welcome sample orders to test and check quality.
Q3: Where can I get the price?
A: We will offer you the best quotation in 12 hours after we get the product specifications such as voltage capacity application etc.
Q4. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q5. How about your delivery time?
A: Generally, it will take 15-30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
